Line Pull and Rope Capacity
| Layer of Wire Rope | Pull by Layer, kg / lb |
Total Rope on the Drum, m / ft | Line Speed | |
| 14 mm rope | 16 mm rope | at 60 l/min (15.9 g/min ), mpm / fpm | ||
| 1st | 9,070 / 20,000 | 12 / 39 | 11 / 36 | 7.1 / 23 |
| 2nd | 7,719 / 17,017 | 27 / 89 | 24 / 79 | 8.3 / 27 |
| 3rd | 6,719 / 14,813 | 43 / 141 | 39 / 128 | 9.5 / 31 |
| 4th | 5,948 / 13,113 | 62 / 203 | 55 / 180 | 10.8 / 35 |
| 5th | 5,335 / 11,762 | 80 / 262 | – | 12 / 39 |
Specifications
- Rated Line Pull 20,000lb (9,070 kg) SAE J706 ratings
- Line Speed (at 1st layer of rope) 23 fpm at 15.9 g/min (7.1 mpm at 60 l/min)
- Operation Pressure 2,540 psi / 175 bar
- Max Oil Flow 15.9 g/min (60 l/min)
- Hydraulic Motor 9.5 cu in (155.7 cc)
- Gear Ratio 2-stage planetary gear 30:1
- Winch Construction Cast housings with steel drum
- Clutch (Freespooling) Output shaft disengaged
- Brake Multi-Disc Brake (MDB) patented
- Rotation of Winch Wire rope shall be under-wound orientation only
- Drum Barrel Diameter 5.8″ (146 mm)
- Drum Flange Diameter 12.4″ (314 mm)
- Distance Between Flanges 14″ (355.6 mm)
- Mounting Bolt Pattern 7.5″ x 18″ (190.5 x 457.2 mm) ; 10.5″ x 18″ (266.7 x 457.2 mm)
- Wire Rope Recommended 9/16″ x 262′ (14 mm x 80 m ) – 1,960 N/mm2 breaking strength of 30,742 lbf (137 kN) required for SAE J706 ratings
- Winch Weight 331 lbs (150 kg)
- Gross Weight 430 lbs (195 kg)
- Box Dimensions 40.4″ x 19.7″ x 20.1″ (1,025 x 500 x 510 mm)
(682385)
