Description
Description
Part Number 123933
Line Speed and Amp. Draw (1st layer of wire rope on the drum):
| Line Pull, kg / lb |
Line Speed, mpm / fpm |
Amp. Draw, A |
| No load | 4.6 / 15.1 | 15 |
| 454 / 1,000 | 3.4 / 11.2 | 60 |
| 907 / 2,000 | 2.9 / 9.5 | 120 |
| 1,361 / 3,000 | 2.4 / 7.9 | 180 |
| 1,814 / 4,000 | 2.0 / 6.6 | 230 |
Line Pull and Rope Capacity:
| Layer of Rope | Pull by layer, kg / lb | Total Rope on the Drum, m / ft |
| 1st | 1,814 / 4,000 | 4 / 13.2 |
| 2nd | 1,535 / 3,385 | 8.8 / 28.8 |
| 3rd | 1,331 / 2,933 | 14.2 / 46.7 |
| 4th | 1,174 / 2,588 | 15.2 / 50 |
Specifications
- Rated Line Pull 4,000 lb (1,814 kg) single line
- Motor 1.0 hp / 800 w 12V, permanent magnet
- Gear Ratio 3-stage planetary 191:1
- Clutch (freespooling) Sliding pin and ring gear
- Brake Mechanical spring applied and permanent magnet motor dynamic brakes
- Winch construction Aluminum die cast housings with steel drum
- Drum size 2.2″ x 4″ x 4.7″ (55 x 104 x 119 mm)
- Remote Control Remote control w / 9.8′ cord
- Rope Type Synthetic rope SK-75
- Rope Size 7/32″ x 50′ (5.5 mm x 15.2 m)
- Mounting Bolt Pattern 3″ x 6.6″ (76 x 165 mm)
- Winch Weight 19 lb / 8.6kg
- Box Dimension 16.1″ x 5.9″ x 13.6″ (410 x 149 x 345 mm)
(123933)
