Dometic Freshjet 5 Mechanical Ac – 13.5K Btu Model Featuring R32 Coolant

Description

Description

FreshJet 5 is Dometic’s low-profile rooftop air conditioner designed as a direct Penguin II replacement. With built-in hard start, quieter performance, a reinforced steel base, and models available with or without a heat pump, it’s engineered for both new RV builds, universal replacements, direct replacement for the Penguin II and upgrades offering modern comfort without changing the fit.

13,500 BTU – Rooftop Low Profile Air Conditioner with R32 Refrigerant – No Pre-installed controls – Non-Ducted application: air distribution box required – Ducted application: return air grille and control kit required, sold separately (PACKAGE CANNOT BE

Features

• More Clearance Flexibility
• Reliable Startup Power
• Quieter Cabin Comfort
• Long-Term Durability
• Enhanced Cooling Longevity
• Simplified Mechanical System

Specifications

Dimensions

• Dimensions product depth, [mm]: 1026.20
• Dimensions product height, [mm]: 742.30
• Dimensions product width, [mm]: 282
• Dimensions product width, [“] – Display: 11.10
• Net weight, [lbs]: 92.39
• Standard mount. material thickness 1 min, [mm]: 18
• Standard mount. material thickness 1 max, [mm]: 68
• Cut out depth, [mm]: 360.000000
• Cut out width, [mm]: 360.000000

Electrical

• Input voltage (AC), [V]: 115
• Input frequency, [Hz]: 60

Performance

• Hermetically Sealed: Yes
• Refrigerant, type: R32
• GWP: 675
• CO2 equivalent, [t]: 0.202
• AirFlow, [m³h]: 483.420000
• Current consumption min cooling, [A]: 12.800000
• Current consumption max cooling, [A]: 19.710000
• Operating temperature min, [°C]: -1.100000

(9620015924)
