Part Number 129302
Line Speed and Amp. Draw (1st layer of wire rope on the drum):
| Line Pull, kg / lb |
Line Speed, mpm / fpm |
Amp. Draw, A |
| 12V | ||
| No load | 5.7 / 18.7 | 25 |
| 227 / 500 | 4.8 / 15.7 | 50 |
| 454 / 1,000 | 4.0 / 13.1 | 80 |
| 680 / 1,500 | 3.5 / 11.5 | 110 |
| 907 / 2,000 | 3.0 / 9.8 | 140 |
| 1,134 / 2,500 | 2.5 / 8.2 | 180 |
| 1,361 / 3,000 | 2.0 / 6.6 | 230 |
Line Pull and Rope Capacity:
| Layer of Rope | Pull by layer, kg / lb | Total Rope on the Drum, m / ft |
| 1st | 1,361 / 3,000 | 2.8 / 9.3 |
| 2nd | 1,173 / 2,585 | 6.1 / 20.1 |
| 3rd | 1,030 / 2,271 | 9.9 / 32.5 |
| 4th | 918 / 2,025 | 14.1 / 46.3 |
| 5th | 829 / 1,827 | 15.2 / 50 |
Specifications:
- Rated Line Pull 3,000 lbs (1,361 kg) single line
- Motor 800 w / 1.0 hp 12V permanent magnet
- Gear Ratio 3-Stage Planetary 138.5:1
- Clutch (freespooling) Sliding pin and ring gear
- Brake Mechanical & Dynamic
- Winch Construction Aluminum Die Cast Housings and Drum
- Drum Size 2.2” x 3” (55 x 75 mm)
- Control Handlebar rocker switch
- Rope Type Synthetic Rope SK-75
- Rope Size 3/16” x 50′ (4.8 mm x 15.2 m)
- Mounting Bolt Pattern 3” x 4.9” (76 x 124 mm)
- Winch Weight 15.9 lbs (7.2 kg)
- Gross Weight 25.3 lbs (11.5 kg)
- Box Dimensions 13.7” x 13” x 5.7” (349 x 331 x 144 mm)
(129302)
